| SPECIFICATIONS / FRAMES | WINDPRO GO | WINDPRO LITE | WINDPRO | WINDPRO PLUS |
|---|---|---|---|---|
| DIMENSIONS |
A1 24"X36" |
A1 A0 B1 22"X28" 24"X36" |
A1 A0 B1 B2 20"X30" 30"X40" 22"X28" 24"X36" |
A1 A0 B1 20"X30" 30"X40" 22"X28" 24"X36" |
| TOP PROFILE | 33 mm Aluminium | 33 mm Aluminium | 40 mm Aluminium | 44 mm Aluminium |
| REAR PROFILE | Standard | Longer and deeper | Standard | Longer and deeper |
| CORNERS | Top 2 corners soft mitred | Top 2 corners soft mitred | Top 2 corners soft square mitred | Top 2 corners soft square mitred |
| PROTECTION COVER | Loose, PET 0,5 mm, antireflex | Loose, PET 0,7 mm UV resistant and antireflex |
Loose, PET 0,7 - 1mm UV resistant and antireflex |
PET 1 mm UV resistant and antireflex, applied in frame with 2 screws |
| BACKING | 4 mm white flusted PP | 4 mm white flusted PP | 4 mm grey flusted PP | 5 mm white flusted PP |
| WATERWICK/GASKET | Without, but with drainage holes on the bottom profile |
Without, but with drainage holes on the bottom profile |
With waterwick/gasket directly in the channel of profile and drainage holes |
With waterwick/gasket directly in the channel of profile and drainage holes |
| SPRINGS | Steel | Steel | Steel | Steel |
| BAR IN BACKING OF FRAME | Without | Without | Without | Without |
| NON-SLIP POSTER TAPE | Without | Without | Without | With poster tape for re-use around 100 times |
| HEADER | Not available | Available by order | Available by order | Available by order |
| PRINT ON PROFILE | 28 mm (h) | 28 mm (h) | 28 mm (h) | 28 mm (h) |
| PRICE | Budget Low Cost | Budget | Economical | Competitive |
| SPECIFICATIONS / WATERBASE | ROTO MOULDED WATERBASE | NEWTECH WATERBASE |
|---|---|---|
| WATERBASE COLOUR | Grey-RAL9006 & Black-RAL 9005 | Grey-RAL9006 & Black-RAL 9005 |
| WATERBASE | Optional Blow molded, or rotative mold. Blow molded 2 dimensions (3,5 ve 4 kg when empty). Rotative base, 2 dimensions (5kg and 6,5kg when empty) |
|
| WATERBASE MATERIAL | LDPE | HDPE |
| PRINT ON WATERBASE | 300 x 80mm & 450 x 90mm | 300 x 80mm & 450 x 90mm |
| COLOURED WATERBASE | MOQ for blow molded: 2000pcs & MOQ for rotative mold: 50pcs per colour + tool cost | |
| CAPACITY | 24lt & 40lt | 30lt & 36.5lts |
| WEIGHT / FULL | 27.5lt & 45kg | 35kg & 43kg |
| WHEELS | 2 wheels | 2 wheels |
| PRICE | Budget | Economical |
Windpro Plus&Lite&Go Match Comparison
Windpro Plus&Lite&Go Match
- Comparison
Click here for the PDF file.
